LTPS-TFT
LCD brings ultra-high resolution
and high brightness images. **
Voice-activated video
transmission.
**
Built-in microphone in camera
for audio monitoring.. **
Monitor can be hooked up to a
VCR for recording. **
Built-in infrared LEDs provides
images even in the darkness.
**
The two-piece design camera lens
body offers flexible adjustment
of rotating angle and
keeps
the lens steady.
**
Both monitor and camera are
battery or AC adapter operated.
**
Both monitor and camera can be
free standing or wall mounted.
**
2.4
GHz signal penetrates walls,
floors, and ceilings.
**
Range
approximately 300 feet clear
line of sight.
CAMERA
**
Frequency
/ 2.4 ~ 2.4835 GHz
**
Range
/ 300 feet (100 meters) clear
line of sight
**
Antennas
/ Built-in omni-directional
antenna
**
Channel
/ 3 selectable channels
**
A/V
mod/demod. method / FM
**
sensor / 1/3" CMOS image
sensor
**
Effective
pixels / NTSC: 510 (H) x 492 (V)
/ PAL: 628 (H) x 582 (V)
**
Lens
/ F6.0mm, F2.0
**
S/N
ratio / >42 dB
**
Microphone
/ Built-in
**
Power
/ DC 9V, 300 mA or 8 AA-size
batteries
**
Dimensions
/ 9.2 x 12.3 x 5.9 cm (3.6x 4.8
x 2.3 in)
**
Weight
/ 175 g (6.17 ounces) without
batteries
**
Operating temperature / 0°C
~ 40°C (32°F ~ 104°F)
MONITOR
**
Frequency / 2.4 ~ 2.4835 GHz
**
Range / 300 feet (100 meters) clear line of sight
**
Antennas / Omni-directional antenna
**
Channel / 3 selectable channels
**
A/V mod/demod. method / FM
**
Display area / 1.5-inch diagonal
**
Display type / LTPS-TFT
**
Resolution / 490 x 240 (117,600 pixels)
**
Brightness / 260 cd/m2
**
Display colors / Full-color
**
Connection terminals / AV output jack
**
Power / DC 5V, 800 mA
**
Dimensions / 8.5 x 14 x 5.3 cm (3.3 x 5.5 x 2.1 in)
**
Weight / 240 g (8.52 ounces)
**
Operating
temperature / 0°C ~ 40°C (32°F
~ 104°F)
|
